2005 Amada EMK 3610NT CNC Turret Punch Press 33 Ton Capacity • 58 Station Turret • AMNC-F Control • 60″ x 196.85″
2005 Amada EMK 3610NT CNC Turret Punch Press equipped with AMNC-F CNC control and a 58-station thick turret with four auto-index stations. This high-speed servo driven turret punch press is designed for precision punching, nibbling, forming, and marking operations in sheet metal fabrication.
The machine features high axis speeds, Fanuc AC servo drives, brush table, and dual work clamps with automatic repositioning capability for processing larger sheets.
Specifications
Manufacturer: Amada
Model: EMK 3610NT
Year: 2005
Control: AMNC-F CNC Control
Punching Capacity: 33 Tons
Maximum Sheet Size:
60″ (Y) x 196.85″ (X) with one reposition cycle
Maximum Axis Travel:
X: 98.425″
Y: 60″
Maximum Material Thickness: 0.187″
Maximum Hole Diameter: 4.5″
Maximum Sheet Weight:
110 lbs (F1)
330 lbs (F4)
Feed Clearance: 0.984″
Stroke Length: 1.45″
Performance
Max Linear Table Speed:
X: 3937 IPM
Y: 3150 IPM
Turret Rotation Speed: 30 RPM
Hit Rate (1″ Pitch):
X: 500 HPM
Y: 330 HPM
Hit Rate (0.039″ Pitch):
X: 780 HPM
Y: 515 HPM
Marking Hit Rate:
X: 1800 HPM
Y: 830 HPM
Minimum Programmable Increment: 0.001″
Tooling System
Turret Type: Amada Thick Turret
Stations: 58
Auto-Index Stations: 4
Auto Index Rotation Speed: 60 RPM
Equipped With
AMNC-F CNC Control
58 Station Turret with 4 Auto-Index
Fanuc AC Servo Drives
Dual Work Clamps
Brush Table
Automatic Repositioning Capability
Self Diagnostics System
Tool Hit Counter
Program Check & Program Setup Modes
Punching Functions
Punching
Nibbling
Forming
Marking
Knockouts
Slotting
Electrical
200 / 208 / 230 / 460 Volt
3 Phase
Power Requirement: 27 kVA
Machine Weight
Approx. 54,000 lbs
Pricing
P.O.R. – Price On Request
Rigging and freight are additional.
